PDSK40 1-1/2"(38MM) Powder Transfer Pump

BULK DENSITY 0.08-0.8 g/cm³ MAX FLOW RATE 2500 Kg/h AIR INLET 3/4"BSPT MAX PRESSURE 8.6bar （125psi） LIQUID INLET 38mm(1-1/2")BSPT MAX DIAMETER SOLIDS 6.3mm(1/4") LIQUID DISCHARGE 38mm(1-1/2")BSPT DISPLACEMENT PER STROKE 1.2L(0.34gal) *1 cycle = 2 strokes CONNECTION TYPE BSPT(Threaded) ANSI DIN(Flanged) MATERIAL AL/316L/CI WEIGHT 36kg(AL)/56(CI/316L) MAX SUCTION LIFT CAPABILITY 5.8m(19')Dry, 9.2m(29.5')Wet MAX OPERATING TEMPERATURE 135℃（275℉）

Hot Tags : Powder Transfer Pump 1-1/2 Inch Powder Transfer Pump Air Operated Double Diaphragm Pump
Read More
H40 1-1/2"(38MM) High Pressure Pump

RATIO 2:1 MAX FLOW RATE 272lpm(72gpm） AIR INLET 3/4"BSPT MAX PRESSURE 14bar（203psi） LIQUID INLET 1.5"（Thread Flanged Clamp） MAX DIAMETER SOLIDS 6.3mm（0.207"） LIQUID DISCHARGE 1.5"（Thread Flanged Clamp） DISPLACEMENT PER STROKE 1.1L(0.29gal)*1 cycle = 2 strokes CONNECTION TYPE BSPT(Threaded) DIN ANSI JIS(Flanged) TRI-Clamp MATERIAL 316L/CI WEIGHT 76KG(CI/316L) MAX SUCTION LIFT CAPABILITY 5.8m(19')Dry, 9.2m(29.5')Wet MAX OPERATING TEMPERATURE 135℃（281℉）

Hot Tags : High Pressure Pump 1-1/2 Inch High Pressure Pump
Read More
SF25 1"(25MM) FDA Pump

SURFACE ROUGHNESS 0.8 MAX FLOW RATE 150lpm(39gpm) AIR INLET 1/2"BSPT MAX PRESSURE 8.6bar （125psi） LIQUID INLET 1"Clamp SMS MAX DIAMETER SOLIDS 6mm(1/4") LIQUID DISCHARGE 1"Clamp SMS DISPLACEMENT PER STROKE 0.3L(0.08gal) *1 cycle = 2 strokes CONNECTION TYPE BSPT(Threaded) DIN ANSI JIS(Flanged) TRI-Clamp MATERIAL 316L WEIGHT 16KG MAX SUCTION LIFT CAPABILITY 4m(13')Dry, 9.2m(30')Wet MAX OPERATING TEMPERATURE 135℃（279℉）

Hot Tags : SF Series FDA Pump 1 Inch FDA Pump
Read More
F20 1/2"(13MM) Hygienic Pump

SURFACE ROUGHNESS 0.4/0.8 MAX FLOW RATE 57lpm(15gpm) AIR INLET 1/2"BSPT MAX PRESSURE 8.6bar （125psi） LIQUID INLET 1"Clamp SMS MAX DIAMETER SOLIDS 6mm(1/4") LIQUID DISCHARGE 1"Clamp SMS DISPLACEMENT PER STROKE 0.15L(0.04gal) *1 cycle = 2 strokes CONNECTION TYPE BSPT(Threaded) DIN ANSI JIS(Flange) TRI-Clamp MATERIAL 316L WEIGHT 11KG MAX SUCTION LIFT CAPABILITY 3m(13')Dry, 9m(30')Wet MAX OPERATING TEMPERATURE 135℃（275℉）

Hot Tags : Hygienic Pump 1/2 Inch Hygienic Pump
Read More
W25 1"(25MM) Sewage Pump

AIR INLET 1/2"BSPT MAX FLOW RATE 170lpm(40gpm) LIQUID INLET 25mm（1"）BSPT MAX PRESSURE 8.6 bar (125 psi) LIQUID DISCHARGE 25mm（1"）BSPT MAX DIAMETER SOLIDS 6mm(1/4") CONNECTION TYPE BSPT(Threaded) ANSI DIN(Flanged) DISPLACEMENT PER STROKE 0.42L(0.11gal) *1 cycle=2 strokes MAX SUCTION LIFT CAPABILITY 3.5m(12')Dry,9.2m(30')Wet MATERIAL AL/316L/CI MAX OPERATING TEMPERATURE 135℃（275℉） WEIGHT 12KG(AL)/19KG(SS/CI)

Hot Tags : Sewage Pump 1 Inch Sewage Pump
Read More
SA25 1"(25MM) Flap Pump

AIR INLET 1/2"BSPT MAX FLOW RATE 170lpm(40gpm) LIQUID INLET 25mm（1"）BSPT MAX PRESSURE 8.6 bar (125 psi) LIQUID DISCHARGE 25mm（1"）BSPT MAX DIAMETER SOLIDS 25mm(1") CONNECTION TYPE BSPT(Threaded) ANSI DIN(Flanged) DISPLACEMENT PER STROKE 0.42L(0.11gal) *1 cycle = 2 strokes MAX SUCTION LIFT CAPABILITY 3.5m(12')Dry, 9.2m(30')Wet MATERIAL AL/316L/CI MAX OPERATING TEMPERATURE 135℃（275℉） WEIGHT 12KG(AL)/19KG(CI/316L)

Hot Tags : SA Series Flap Pump 1 Inch Flap Pump
Read More
PS15 1/2"(13 MM) Plastic AODD Pump

AIR INLET 1/4"BSPT MAX FLOW RATE 52lpm(13.5gpm) LIQUID INLET 13mm（1/2"）BSPT MAX PRESSURE 6.9bar(100psi) LIQUID DISCHARGE 13mm（1/2"）BSPT MAX DIAMETER SOLIDS 3mm(0.118") CONNECTION TYPE BSPT(Threaded) ANSI DIN(Flanged) DISPLACEMENT PER STROKE 0.15L(0.04gal) *1 cycle=2 strokes MAX SUCTION LIFT CAPABILITY 3.5m(12')Dry,9.2m(30')Wet MATERIAL PP/PVDF/PPH MAX OPERATING TEMPERATURE PP(80℃)PVDF(95℃) WEIGHT 5.5KG（PP)/7.2KG(PVDF)

Hot Tags : 1/2 Inch Plastic AODD Pump Plastic AODD Pump
Read More
SK15 1/2"(13 MM) Metal AODD Pump

AIR INLET 1/4"BSPT MAX FLOW RATE 57lpm(15gpm) LIQUID INLET 13mm（1/2"）BSPT MAX PRESSURE 8.6 bar (125 psi) LIQUID DISCHARGE 13mm（1/2"）BSPT MAX DIAMETER SOLIDS 2.4mm(3/32") CONNECTION TYPE BSPT(Threaded) ANSI DIN(Flanged) DISPLACEMENT PER STROKE 0.15L(0.04gal) *1 cycle = 2 strokes MAX SUCTION LIFT CAPABILITY 3m(10')Dry,9.0m(30')Wet MATERIAL AL/316L/CI MAX OPERATING TEMPERATURE 135℃（275℉） WEIGHT 8KG(AL)/10KG(CS/SS)

Hot Tags : 1/2 Inch Metal AODD Pump Metal AODD Pump
Read More
