- Top in and bottom out design can directly push out the solid to eliminate the damage caused by solid settlement in the pump
- Large internal clearance enables solid particles with a maximum diameter of 56 mm or compressible elastic solids with a diameter of up to 76 mm to pass through
- Excellent performance: the vane valve pump can work in applications where the pump needs to be completely submerged
- External repairable gas circuit control system
- Inlet and outlet rotary connection, outlet direction optional - 90 ° - 180 °
- Full bolt structure-- Durable, high pressure
- Easy maintenance
- Improve work efficiency
- Reduce operating costs
Characteristic
Used to transport fluids containing large particle solids
Dimensions
| MATERIALS | PART |
|---|---|
| Material of wetted parts | Aluminum alloy, cast iron, 316L stainless steel |
| Material of non-wetted parts | Center body (aluminum alloy(electrophoresis),anodized aluminum, PP polypropylene, 316L stainless steel) |
| Air valve | Aluminum alloy(electrophoresis),anodized aluminum, PP polypropylene, 316L stainless steel |
| MATERIALS | PART |
|---|---|
| Santoprene | -40°C to 107°C (-40°F to 225°F) |
| Neoprene | -18°C to 93°C (0°F to 200°F) |
| Polytetrafluoroethylene (PTFE) | 4°C to 104°C (40°F to 220°F) |
| Nitrile rubber (Buna-N) | -12°C to 82°C (10°F to 180°F) |
| EPDM | -51°C to 138°C (-60°F to 280°F) |
| Fluorine rubber (FKM) | -40°C to 177°C (-40°F to 350°F) |
Accessories
