E25 1"(25 MM) EODD Pump

MOTOR POWER 1.5 kw MAX FLOW RATE 9m³/h MAXIMUM MOTOR SPEED 129 r/min MAX PRESSURE 4bar （58psi） LIQUID INLET 25mm（1"）BSPT MAX DIAMETER SOLIDS 6mm(1/4") LIQUID DISCHARGE 25mm（1"）BSPT DISPLACEMENT PER STROKE 0.42L(0.11gal) *1 cycle=2 strokes CONNECTION TYPE BSPT(Threaded) ANSI DIN(Flanged) MATERIAL 316L/CI/PP/PVDF/PPH MAX SUCTION LIFT CAPABILTY 3.5m(12')Dry,9.2m(30')Wet MAX OPERATING TEMPERATURE 135℃（275℉）

Hot Tags : EODD Pump 1 Inch EODD Pump Electric Double Diaphragm Pump
Read More
E40 1.5"(38 MM) EODD Pump

MOTOR POWER 3 kw MAX FLOW RATE 20m³/h MAXIMUM MOTOR SPEED 111 r/min MAX PRESSURE 4bar （58psi） LIQUID INLET 38mm(1-1/2")BSPT MAX DIAMETER SOLIDS 6.3mm(1/4") LIQUID DISCHARGE 38mm(1-1/2")BSPT DISPLACEMENT PER STROKE 1.29L(0.34gal) *1 cycle=2 strokes CONNECTION TYPE BSPT(Threaded) ANSI DIN(Flanged) MATERIAL 316L/CI/PP/PVDF/PPH MAX SUCTION LIFT CAPABILTY 3.5m(12')Dry,9.2m(30')Wet MAX OPERATING TEMPERATURE 135℃（275℉）

Hot Tags : 1.5 Inch EODD Pump
Read More
E50 2"(51 MM) EODD Pump

MOTOR POWER 4 kw MAX FLOW RATE 24m³/h MAXIMUM MOTOR SPEED 102 r/min MAX PRESSURE 4bar （58psi） LIQUID INLET 51mm(2")BSPT MAX DIAMETER SOLIDS 9mm(3/8") LIQUID DISCHARGE 51mm(2")BSPT DISPLACEMENT PER STROKE 1.63L(0.43gal) *1 cycle=2 strokes CONNECTION TYPE BSPT(Threaded) ANSI DIN(Flanged) MATERIAL 316L/CI/PP/PVDF/PPH MAX SUCTION LIFT CAPABILTY 5m(16')Dry,9.2m(30')Wet MAX OPERATING TEMPERATURE 135℃（275℉）

Hot Tags : 2 Inch EODD Pump
Read More
E80 3" (76 MM) EODD Pump

MOTOR POWER 7.5 kw MAX FLOW RATE 48m³/h MAXIMUM MOTOR SPEED 84 r/min MAX PRESSURE 4bar （58psi） LIQUID INLET 76mm（3"）BSPT MAX DIAMETER SOLIDS 12mm(0.472") LIQUID DISCHARGE 76mm（3"）BSPT DISPLACEMENT PER STROKE 3.62L(0.95gal) *1 cycle=2 strokes CONNECTION TYPE BSPT(Threaded) ANSI DIN(Flanged) MATERIAL 316L/CI/PP/PVDF/PPH MAX SUCTION LIFT CAPABILTY 5m(16')Dry,9.5m(30.4')Wet MAX OPERATING TEMPERATURE 135℃（275℉）

Hot Tags : 3 Inch EODD Pump
Read More
