H50 2"(51MM) High Pressure Pump

RATIO 2:1 MAX FLOW RATE 408lpm(108gpm） AIR INLET 3/4"BSPT MAX PRESSURE 14bar（203psi） LIQUID INLET 2"（Thread Flanged Clamp） MAX DIAMETER SOLIDS 9mm(0.375") LIQUID DISCHARGE 2"（Thread Flanged Clamp） DISPLACEMENT PER STROKE 2.6L(0.7gal) *1 cycle = 2 strokes CONNECTION TYPE BSPT(Threaded) DIN ANSI JIS(Flanged) TRI-Clamp MATERIAL 316L/CI WEIGHT 93KG(CI/316L) MAX SUCTION LIFT CAPABILITY 6m(20')Dry, 9.2m(30')Wet MAX OPERATING TEMPERATURE 135℃（281℉）

Hot Tags : High Pressure Pump 2 Inch High Pressure Pump Air Operated Double Diaphragm Pump
Read More
SF40 1-1/2"(38MM) FDA Pump

SURFACE ROUGHNESS 0.8 MAX FLOW RATE 340.7lpm(90gpm) AIR INLET 3/4"BSPT MAX PRESSURE 8.6bar （125psi） LIQUID INLET 2"Clamp SMS MAX DIAMETER SOLIDS 8mm(0.315") LIQUID DISCHARGE 2"Clamp SMS DISPLACEMENT PER STROKE 1.1L(0.29gal) *1 cycle = 2 strokes CONNECTION TYPE BSPT(Threaded) DIN ANSI JIS(Flanged) TRI-Clamp MATERIAL 316L WEIGHT 50KG MAX SUCTION LIFT CAPABILITY 5.8m(19')Dry, 9.2m(29.5')Wet MAX OPERATING TEMPERATURE 135℃（279℉）

Hot Tags : FDA Pump 1-1/2 Inch FDA Pump
Read More
F25 1"(25MM) Hygienic Pump

SURFACE ROUGHNESS 0.4/0.8 MAX FLOW RATE 150lpm(39gpm) AIR INLET 1/2"BSPT MAX PRESSURE 8.6bar （125psi） LIQUID INLET 1"Clamp SMS MAX DIAMETER SOLIDS 6mm(1/4") LIQUID DISCHARGE 1"Clamp SMS DISPLACEMENT PER STROKE 0.3L(0.08gal) *1 cycle = 2 strokes CONNECTION TYPE BSPT(Threaded) DIN ANSI JIS(Flanged) TRI-Clamp MATERIAL 316L WEIGHT 16KG MAX SUCTION LIFT CAPABILITY 4m(13')Dry, 9.2m(30')Wet MAX OPERATING TEMPERATURE 135℃（275℉）

Hot Tags : Hygienic Pump 1 Inch Hygienic Pump
Read More
W40 1-1/2"(38MM) Sewage Pump

AIR INLET 3/4" BSPT MAX FLOW RATE 340.7lpm(90gpm) LIQUID INLET 38mm(1-1/2")BSPT MAX PRESSURE 8.6 bar (125 psi) LIQUID DISCHARGE 38mm(1-1/2")BSPT MAX DIAMETER SOLIDS 6.3mm(1/4") CONNECTION TYPE BSPT(Threaded) ANSI DIN(Flanged) DISPLACEMENT PER STROKE 1.29L(0.34gal) *1 cycle=2 strokes MAX SUCTION LIFT CAPABILITY 5.8m(19')Dry,9.2m(29.5')Wet MATERIAL AL/316L/CI MAX OPERATING TEMPERATURE 135℃（275℉） WEIGHT 36KG(AL)/56KG(CI/316L)

Hot Tags : Sewage Pump 1-1/2 Inch Sewage Pump
Read More
SA50 2"(51MM) Flap Pump

AIR INLET 3/4"BSPT MAX FLOW RATE 511lpm(135gpm) LIQUID INLET 51mm(2")BSPT MAX PRESSURE 8.6 bar (125 psi) LIQUID DISCHARGE 51mm(2")BSPT MAX DIAMETER SOLIDS 45mm(1.8") CONNECTION TYPE BSPT(Threaded) ANSI DIN(Flanged) DISPLACEMENT PER STROKE 1.63L(0.43gal) *1 cycle = 2 strokes MAX SUCTION LIFT CAPABILITY 6m(20')Dry, 9.2m(30')Wet MATERIAL AL/316L/CI MAX OPERATING TEMPERATURE 135℃（275℉） WEIGHT 36KG(AL)/56KG(CI/316L)

Hot Tags : Flap Pump 2 Inch Flap Pump
Read More
PS25 1"(25 MM) Plastic AODD Pump

AIR INLET 1/2"BSPT MAX FLOW RATE 158lpm(42gpm) LIQUID INLET 25mm（1"）FLANGE MAX PRESSURE 6.9bar(100psi) LIQUID DISCHARGE 25mm（1"）FLANGE MAX DIAMETER SOLIDS 6mm(0.25") CONNECTION TYPE ANSI DIN(Flanged) DISPLACEMENT PER STROKE 0.42L(0.11gal) *1 cycle=2 strokes MAX SUCTION LIFT CAPABILITY 3.5m(12')Dry,9.2m(30')Wet MATERIAL PP/PVDF/PPH MAX OPERATING TEMPERATURE PP(80℃)PVDF(95℃) WEIGHT 12KG（PP)/16KG(PVDF)

Hot Tags : 1 Inch Plastic AODD Pump Plastic AODD Pump
Read More
LS25K 1"(25 MM) Metal AODD Pump

AIR INLET 1/2"BSPT MAX FLOW RATE 150lpm(40gpm) LIQUID INLET 25mm（1"）BSPT MAX PRESSURE 8.6 bar (125 psi) LIQUID DISCHARGE 25mm（1"）BSPT MAX DIAMETER SOLIDS 6mm(1/4") CONNECTION TYPE BSPT(Threaded) ANSI DIN(Flanged) DISPLACEMENT PER STROKE 0.42L(0.11gal) *1 cycle=2 strokes MAX SUCTION LIFT CAPABILITY 3.5m(12')Dry,9.2m(30')Wet MATERIAL AL/316L/CI MAX OPERATING TEMPERATURE 135℃（275℉） WEIGHT 12KG(AL)/19KG(SS/CI)

Hot Tags : 1 Inch Metal AODD Pump Metal AODD Pump
Read More
H80 3"(76MM) High Pressure Pump

RATIO 2:1 MAX FLOW RATE 790lpm(209gpm） AIR INLET 3/4"BSPT MAX PRESSURE 14bar（203psi） LIQUID INLET 3"（Thread Flanged Clamp） MAX DIAMETER SOLIDS 15mm(0.6") LIQUID DISCHARGE 3"（Thread Flanged Clamp） DISPLACEMENT PER STROKE 5.15L(1.32gal) *1 cycle = 2 strokes CONNECTION TYPE BSPT(Threaded) DIN ANSI JIS(Flanged) TRI-Clamp MATERIAL 316L/CI WEIGHT 200KG(CI/316L) MAX SUCTION LIFT CAPABILITY 6m(20')Dry, 9.5m(30')Wet MAX OPERATING TEMPERATURE 135℃（281℉）

Hot Tags : 3 Inch High Pressure Pump
Read More
