PS Series Plastic Pump

Plastic AODD Pumps – Lightweight & Chemical-Resistant Diaphragm Pump Solutions

What is a Plastic AODD Pump?

A Plastic AODD (Air-Operated Double Diaphragm) Pump is a diaphragm pump made primarily from plastic materials like PP (Polypropylene), PVDF or PPH. These pumps are ideal for handling corrosive, acidic, or abrasive fluids where metal components would corrode or degrade. Skylink’s PS-Series Plastic AODD Pumps are designed for chemical resistance, light weight, and reliable performance in industries such as chemical processing, food & beverage, pharmaceutical washdowns, paint & coatings, and water treatment.

Product Models & Key Specifications

Model	Liquid Inlet / Discharge Size	Max Flow Rate	Max Solid Particle Size	Materials Available	Max Pressure / Operating Temp
PS15 (½”)	13 mm (1/2″) BSPT threads	52 LPM (13.5 GPM)	3 mm	PP / PVDF / PPH	6.9 bar / PP: 80 °C • PVDF: 95 °C
PS25 (1”)	25 mm (1″) flange	158 LPM (42 GPM)	6 mm	PP / PVDF / PPH	6.9 bar / 80-95 °C
PS40 (1½”)	38 mm flange	340 LPM (90 GPM)	6.3 mm	PP / PVDF / PPH	6.9 bar / 80-95 °C
PS50 (2”)	51 mm flange	511 LPM (135 GPM)	9 mm	PP / PVDF / PPH	6.9 bar / 80-95 °C
PS80 (3”)	76 mm flange	988 LPM (260 GPM)	15 mm	PP / PVDF / PPH	6.9 bar / 80-95 °C

Flanged or threaded connections available. Custom variants and accessories upon request.

Why Choose Skylink Plastic AODD Pumps?

Chemical Resistance – Constructed of polypropylene (PP), PVDF, or PPH, these pumps are resistant to many acids, alkalis, solvents, and harsh chemicals.
Lightweight & Cost-Effective – Plastic materials reduce weight and cost compared to metal, making transport and installation easier.
Large Solids Handling – Models support solids up to 15 mm (PS80), minimizing clogging in slurry or semi-solid fluids.
Moderate Pressure & Temperature Range – Rated up to 6.9 bar and 80-95 °C, suitable for many industrial fluid applications.
Flexible Connections – Available with BSPT threads or ANSI/DIN flanged ends for varied piping systems.
