| OUTPUT | 0.09 ml/rev |
| MAXIMUM SPEED | 6000 RPM |
| MAX FLOW RATE | @1450PRM 130 ml/min |
| MAX FLOW RATE | @2830PRM 250 ml/min |
| MAX FLOW RATE | @6000PRM 540 ml/min |
| MAX DIFFERENTIAL PRESSURE | 10 bar |
| MAX INLET PRESSURE | 100 bar |
| WITHSTAND MAX NEGATIVE PRESSURE | 250 mbar |
| TEMPERATURE RANGE | -20°C to 130°C |
| VISCOSITY RANGE | 5 to 3000 mPas |
| DIRECTION OF ROTATION | 可选 |
| INTERFACE SPECIFICATION | G 1/8 ", NPT 1/8 " |
| BYPASS OVERFLOW VALVE | Available |
| PRESSURE CONTROL VALVE | Not available |
| MAX TRANSMISSION TORQUE OF MAGNETIC DRIVE | 250 mNm |
